Standards

EN 418,ISO13850,ISOTR12100,IEC60947-5-1, IEC60947-5-5

Approvals

CEmarkedfor allapplicabledirectives,cULus andTUV

Safety Contact

2 N.C. or3 N.C. or4 N.C.directopeningaction

Designation/UtilizationCat. A600/AC-15 (Ue)(Ie) N600/DC-13 (Ue)(Ie)

600V500V240V120V

1.2A 1.4A3A 6A600V500V250V125V

0.4A0.55A1.1A 2.2A

Thermal Current (lth)

10 A

Minimum Current

5 V 5 mA

Safety Contact Gap

>2 x 2mm(0.078in)

Rtd. ImpulseWithstand Voltage

(Uimp)2500 V

Pollution Degree

3

Max. ActuationFrequency

1 cycle/s

Case Material

Heavy-duty die-castaluminiumalloy(LM24)

Eye Nut Material

Stainlesssteel

Indicator Material

Glassfillednylon

Protection

IP67

Conduit Entry

1 x 1/2inNPT, 1 xM20,quick-disconnectstyle

OperatingTemperature

-25°C to+80°C(-13°F to+176°F)

Operation Force

<125N(28.1lb)(300mmdeflection)

Tensioning Force toRun Position

103N(23.17lb)typical

Tensioning Force toLockout

188N(42.3lb)typical

Max. Cable SpanBetween Switches

30m(98.42ft)

Fixing (mountingholes)

4 x M5

Mounting

Anyposition

Mechanical Life

1,000,000

Weight

610g(1.34lb)

Colour

Yellowbody, blueresetbutton
